Features
Audio output channels7.1 channels
Component forPC
Motherboard chipsetAMD B550
Motherboard chipset familyAMD
Motherboard form factormicro ATX
Product colourMulticolour
Windows operating systems supportedWindows 10 x64/Windows 11 x64
Processor
Compatible processor seriesAMD Ryzen 3000 Series/AMD Ryzen 5000 Series
Processor manufacturerAMD
Processor socketSocket AM4
Supported processor socketsSocket AM4
Memory
ECC сompatibilityECC
Maximum internal memory128 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory clock speeds2133/2400/2666/2800/3000/3200/3333/3466/3600/3733/3866/4000/4133/4266/4400/4466/4600/4800/4866 MHz
Supported memory typesDDR4-SDRAM
Unbuffered memoryYes
Storage controllers
Number of storage drives supported6
RAID levels0/1/10
RAID supportYes
Supported storage drive interfacesM.2,PCI Express 3.0,PCI Express 4.0,SATA III
Supported storage drive typesHDD & SSD
Graphics
On-board graphics cardNo
Parallel processing technology supportNot supported
Internal I/O
12V power connectorYes
ATX Power connector (24-pin)Yes
CPU fan connectorYes
EPS power connector (8-pin)Yes
Front panel audio connectorYes
Number of chassis fan connectors2
Number of COM connectors1
Number of EATX power connectors1
Number of SATA III connectors4
RGB LED pin headerYes
S/PDIF out connectorYes
TPM connectorYes
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Rear panel I/O ports
DVI-D ports quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
HDMI version2.1
Headphone outputs1
Microphone inYes
PS/2 ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB connector typeUSB Type-A
VGA (D-Sub) ports quantity1
WiFi-AP antenna jack1
Network
BluetoothYes
Bluetooth version5.2
Ethernet interface typeGigabit Ethernet
Ethernet LANYes
LAN controllerRealtek RTL8111H
Top Wi-Fi standardWi-Fi 6 (802.11ax)
Wake-on-LAN readyYes
Wi-FiYes
Wi-Fi standards802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)
Expansion slots
1st M.2 highest PCI Express generation4.0
1st M.2 largest key size22110
2nd M.2 highest PCI Express generation3.0
2nd M.2 largest key size2280
Number of M.2 (M) slots2
PCI Express x1 (Gen 3.x) slots2
PCI Express x16 (Gen 4.x) slots1
BIOS
BIOS memory size256 Mbit
BIOS typeUEFI AMI
Clear CMOS jumperYes
Logistics data
Harmonized System (HS) code84733020
Weight & dimensions
Depth244 mm
Height67 mm
Width244 mm
Packaging content
Cables includedSATA
Drivers includedYes
Other features
Packaging content2 x SATA 6Gb/s cables
1 x ASUS Wi-Fi moving antennas
1 x I/O Shield
1 x M.2 SSD screw package
1 x Support DVD
1 x User manual
Weight845 g
Category CodeMBA
Unit Box Height0.07
Unit Box Length0.28
Unit Box Width0.27
Units per Pallet0
Units per Shipping Box10
Unit Calculated Volume0.006438 cubm
Unit Calculated Weight1.31 kg
